Threat Intelligence Brief and SOC Enhancement Plan¶

PMG Medical Centre

Created By: Paul Leone
Date: October 6, 2025
Organization: Piedmont Medical Group (PMG)

1. Threat Intelligence Brief¶

1.1 Purpose¶

This brief delivers a focused overview of UNC5221, a threat actor that presents significant risks to Piedmont Medical Group (PMG) and the broader healthcare sector. The purpose of this document is to inform PMG's IT team and healthcare staff by providing context, analysis, and tailored recommendations based on PMG's specific IT environment and operational needs.

To begin, the background summary will contextualize UNC5221's activities and objectives in the healthcare industry. Following the background summary, the threat analysis will detail how UNC5221's tactics, techniques, and procedures (TTPs) align with the MITRE ATT&CK framework. The MITRE ATT&CK framework is a globally recognized knowledge base that categorizes adversary tactics and techniques observed in real-world incidents.

After the threat analysis, the report will summarize the vulnerabilities most relevant to PMG, with a focus on those affecting the organization's technology stack and network. This section will make clear how these vulnerabilities could impact PMG's infrastructure.

Building on the vulnerabilities discussion, the document will address the malware toolkits deployed by UNC5221, explaining their potential effects on PMG's systems. The report will then conclude with actionable recommendations for detection and mitigation, all of which are customized to address the unique IT infrastructure and operational requirements of Piedmont Medical Group.

As a follow-up, a Security Operations Center (SOC) detection strategy and rule deployment document will be provided to the IT team for further review. This accompanying document will include: an inventory of critical log sources and telemetry for PMG's assets; detection rule suggestions mapped to the observed TTPs; and proposed enhancements for dashboards and SOC workflows, ensuring that all guidance is directly relevant to PMG's environment.

1.2 Overview of UNC5221 Threat Landscape¶

1.2.1 Background¶

UNC5221 is a China-nexus espionage threat actor that the PMG CTI team has been actively tracking since October 2023. This group has increasingly focused its operations on the healthcare sector, targeting critical infrastructure and sensitive patient data within hospitals, clinics, and healthcare service providers.

Their primary initial access vector remains the exploitation of vulnerabilities in widely deployed enterprise-grade Virtual Private Network (VPN) appliances, such as Ivanti Connect Secure. After gaining a foothold, UNC5221 leverages a custom malware toolset designed for stealth and persistent presence within healthcare IT systems.

In April 2025, UNC5221 exploited a critical buffer overflow vulnerability, CVE-2025-22457, in Ivanti Connect Secure VPN appliances.
Since April 2024, UNC5221 has been observed exploiting vulnerabilities in edge devices, used compromised credentials, and deployed the BRICKSTORM backdoor in a campaign targeting the legal and software industries in the United States (CAMP.25.044).

1.3 Threat Analysis – Ivanti Connect Secure¶

This report focuses specifically on PMG and its current VPN infrastructure. At present, PMG's attack surface includes only Ivanti VPN endpoints; Fortinet and Citrix VPN solutions are not deployed within the organization. Accordingly, the analysis will address only Ivanti-specific CVEs and related recommendations.

1.3.1 Vulnerabilities Overview¶

CVE-2023-46805 – Ivanti Connect Secure / Policy Secure Authentication Bypass¶

Overview: An authentication bypass vulnerability in the web component of Ivanti Connect Secure (ICS) and Ivanti Policy Secure gateways. Allows unauthenticated attackers to access restricted resources by bypassing control checks.

Affected Products: - Ivanti Connect Secure - Ivanti Policy Secure - Ivanti ZTA Gateways

Impacted Versions: - Ivanti Connect Secure: 9.x and 22.x (e.g., 9.1R18.3) - Ivanti Policy Secure: Same versions

Attack Vector: - Remote unauthenticated access via crafted HTTP requests to Ivanti VPN endpoints

Exploitation: - Often chained with CVE-2024-21887 for unauthenticated remote code execution - Used by threat actors like UNC5221 and UTA0178 to deploy webshells

Impact: - Severity: CVSS 9.8 (Critical) - Effect: Full remote code execution without authentication - Scope: Allows attackers to deploy malware, establish persistence, and pivot laterally into internal networks

Mitigations: - Patch to versions: 9.1R18.4, 9.1R17.3, 22.6R2.2, etc. - A patch was released for ICS 22.2R3 on June 4, 2024. Previous releases were patched on February 8th for Ivanti Connect Secure (versions 9.1R14.5, 9.1R17.3, 9.1R18.4, 22.4R2.3, 22.5R1.2, 22.5R2.3 and 22.6R2.2), Ivanti Policy Secure (versions 9.1R17.3, 9.1R18.4 and 22.5R1.2) and ZTA gateways (versions 22.5R1.6, 22.6R1.5 and 22.6R1.7)) and 14th (for Ivanti Connect Secure (versions 9.1R15.3, 9.1R16.3, 22.1R6.1, 22.2R4.1, 22.3R1.1 and 22.4R1.1) and Ivanti Policy Secure (versions 9.1R16.3, 22.4R1.1 and 22.6R1.1) respectively - Ivanti released mitigation scripts for unpatched systems - CISA added this to its Known Exploited Vulnerabilities (KEV) catalog

CVE-2024-21887 – Ivanti Command Injection¶

Overview: A command injection vulnerability in Ivanti ICS and Policy Secure allowing authenticated administrators to execute arbitrary commands.

Affected Products: - Ivanti Connect Secure - Ivanti Policy Secure

Impacted Versions: - Ivanti Connect Secure: 9.x and 22.x (e.g., 9.1R18.3) - Ivanti Policy Secure: Same versions

Exploitation: - Often chained with CVE-2023-46805 for unauthenticated RCE - Used by UNC5221 and other actors to deploy malware and webshells

Mitigations: - Patch to 9.1R18.4 and other listed versions - Apply Ivanti's mitigation script if patching is delayed

CVE-2025-22457 - Ivanti Stack-Based Buffer Overflow¶

Overview: Stack-based buffer overflow in Ivanti Connect Secure, Policy Secure, and ZTA Gateways.

Affected Products: - Ivanti Connect Secure - Ivanti Policy Secure - Ivanti ZTA Gateways

Impacted Versions: - Ivanti Connect Secure: 9.x and 22.x (e.g., 9.1R18.3) - Ivanti Policy Secure: Same versions

Impact: - Remote unauthenticated code execution - CVSS: 9.8 (Critical) - Exploited In Wild: Yes — attributed to UNC5221 (China-nexus actor)

Malware Dropped: - TRAILBLAZE (in-memory dropper) - BRUSHFIRE (passive backdoor) - SPAWN ecosystem (previously linked to UNC5221)

Mitigations: - Patch to 9.1R18.4 and other listed versions - A patch for CVE-2025-22457 was released in ICS 22.7R2.6 on February 11, 2025. The vulnerability is a buffer overflow with a limited character space, and therefore it was initially believed to be a low-risk denial-of-service vulnerability. We assess it's likely the threat actor studied the patch for the vulnerability in ICS 22.7R2.6 and uncovered through a complicated process, it was possible to exploit 22.7R2.5 and earlier to achieve remote code execution

Summary¶

Directly Associated: 3 tools (TRAILBLAZE, BRUSHFIRE, SPAWNSLOTH)
Possibly Associated: 6 tools (SPAWNWAVE, ZIPLINE, Brickstorm, Earthworm, Lightwire, Neo-reGeorg)

TRAILBLAZE¶

TRAILBLAZE is an in-memory only dropper written in bare C that uses raw syscalls and is designed to be as minimal as possible, likely to ensure it can fit within the shell script as Base64. TRAILBLAZE injects a hook into the identified /home/bin/web process. It will then inject the BRUSHFIRE passive backdoor into a code cave inside that process.

Threat Correlation: In-memory dropper deployed via shell injection; fits within login.cgi exploit chain.

BRUSHFIRE¶

BRUSHFIRE is a passive backdoor written in bare C that acts as an SSL_read hook. It first executes the original SSL_read function, and checks to see if the returned data begins with a specific string. If the data begins with the string, it will XOR decrypt then execute shellcode contained in the data. If the received shellcode returns a value, the backdoor will call SSL_write to send the value back.

Threat Correlation: Passive backdoor injected by TRAILBLAZE into /home/bin/web; core persistence mechanism.

SPAWNSLOTH¶

As detailed in our previous blog post, SPAWNSLOTH acts as a log tampering component tied to the SPAWNSNAIL backdoor. It targets the dslogserver process to disable both local logging and remote syslog forwarding.

Threat Correlation: Log tampering component used post-exploitation to disable dslogserver and evade detection.

SPAWNWAVE¶

SPAWNWAVE is an evolved version of SPAWNANT that combines capabilities from other members of the SPAWN* malware ecosystem. SPAWNWAVE overlaps with the publicly reported SPAWNCHIMERA and RESURGE malware families.

Threat Correlation: Part of SPAWN ecosystem; overlaps with malware families used by UNC5221 in Ivanti campaigns.

ZIPLINE¶

ZIPLINE is a passive backdoor that was used during Cutting Edge on compromised Secure Connect VPNs for reverse shell and proxy functionality.

Threat Correlation: Passive backdoor used in Secure Connect VPN exploitation; may overlap with Ivanti tooling.

BRICKSTORM¶

Brickstorm is a sophisticated and highly evasive cyberespionage backdoor tool, primarily associated with the China-aligned threat group UNC5221. The malware has been used in long-term espionage campaigns to infiltrate and steal intellectual property and other sensitive information from high-value targets, particularly in Europe.

Threat Correlation: UNC5221-linked espionage tool; may be deployed post-access for long-term persistence.

EARTHWORM¶

A simple network tunnel with SOCKS v5 server and port transfer. It works well in various situations. It supports "forward", "backward" and "multi-transfer" modes and can penetrate deeply into the intranet. It supports various OS such as Linux, Windows, MacOS, Arm-Linux. Adversaries may tunnel network communications to and from a victim system within a separate protocol to avoid detection and network filtering, or to enable access to otherwise unreachable systems.

Threat Correlation: Network tunneling tool; useful for C2 or lateral movement post-Ivanti compromise.

LIGHTWIRE¶

LIGHTWIRE is a web shell written in Perl that was used during Cutting Edge to maintain access and enable command execution by embedding into the legitimate compcheckresult.cgi component of Ivanti Secure Connect VPNs.

Threat Correlation: Web shell embedded in Ivanti CGI component; aligns with CVE-2024-21887 exploitation.

NEO-reGEORG¶

Neo-reGeorg is an open-source web shell designed as a restructuring of reGeorg with improved usability, security, and fixes for existing reGeorg bugs.

Threat Correlation: Open-source web shell; commonly used in VPN appliance exploitation scenarios.

1.3.3 MITRE ATT&CK Mapping for Ivanti CVEs¶

MITRE ATT&CK Framework Visualization

Tactic	Technique ID	Technique Name	Description
Initial Access	T1190	Exploit Public-Facing Application	Attackers exploit Ivanti VPN endpoints to gain unauthenticated access
Execution	T1059.004	Command and Scripting Interpreter: Unix Shell	Shell commands injected via login.cgi to execute payloads like TRAILBLAZE
Persistence	T1505.003	Server Software Component: Webshell	BRUSHFIRE backdoor embedded in /home/bin/web for long-term access
Defense Evasion	T1562.001	Impair Defenses: Disable or Modify Tools	Ivanti's integrity checker tool (ICT) is tampered to avoid detection
Command & Control	T1071.001	Application Layer Protocol: Web	BRUSHFIRE uses passive HTTP/S beaconing for stealthy C2 communication
Credential Access	T1003	OS Credential Dumping	VPN session tokens and credentials are harvested post-exploitation
Exfiltration	T1041	Exfiltration Over C2 Channel	Data exfiltrated via encrypted channels from compromised appliances
Lateral Movement	T1021.004	Remote Services: SSH	SPAWN toolkit used to pivot across systems using SSH and remote shells
Defense Evasion	T1027	Obfuscated Files or Information	TRAILBLAZE is packed and Base64-encoded in shell scripts
Defense Evasion	T1036	Masquerading	BRUSHFIRE masquerades as legitimate SSL_read hook
Defense Evasion	T1222	File and Directory Permissions Modification	Used to persist implants in /home/bin/web with modified perms
Discovery	T1016	System Network Configuration Discovery	SPAWN tools perform network recon for lateral movement
Discovery	T1033	System Owner/User Discovery	Used to identify privileged accounts post-access
Discovery	T1057	Process Discovery	TRAILBLAZE targets running processes for injection
Discovery	T1082	System Information Discovery	Recon phase includes OS fingerprinting
Discovery	T1083	File and Directory Discovery	SPAWN tools enumerate file paths for implant placement
Discovery	T1518	Software Discovery	SPAWNSLOTH disables dslogserver and remote syslog
Execution	T1047	Windows Management Instrumentation	Used in lateral movement and remote command execution (especially in hybrid Windows environments)

MITRE ATT&CK Framework Visualization

1.3.4 Risk Assessment¶

The following table outlines the potential risk and impact to PMG.

Category	Risk / Impact
Remote Access Compromise	VPN gateway exploitation allows attackers to bypass authentication and gain full access to internal systems
Patient Data Exposure	Attackers can exfiltrate PHI (Protected Health Information), violating HIPAA and triggering breach notifications
Malware Deployment	TRAILBLAZE and BRUSHFIRE enable stealthy persistence and remote control, often undetected by traditional AV
Credential Theft	VPN session tokens and cached credentials can be harvested, enabling lateral movement and privilege escalation
Operational Disruption	Attackers may disable logging (via SPAWNSLOTH), tamper with integrity tools, or crash services, impacting care delivery
Compliance Violations	Failure to patch or detect exploitation could result in regulatory penalties and loss of accreditation
Third-Party Risk	Compromised VPNs may be used to pivot into EHR systems, billing platforms, or partner networks
Reputation Damage	Public disclosure of a breach tied to known CVEs can erode patient trust and damage institutional credibility
Incident Response Overload	Without automation or SOAR playbooks, even a single compromise can overwhelm IT and compliance teams

1.3.5 Recommendations for Mitigation and Detection¶

This section outlines high-level mitigation and detection strategies for Ivanti-related CVEs exploited by UNC5221. Detailed configuration guidance and workflow enhancements are provided in the accompanying solution document. Note that these recommendations include potential additions to the existing toolset.

These recommendations are intended for organizations currently using Ivanti products and may require adaptation based on individual infrastructure and security policies. For step-by-step implementation details and workflow integration, please refer to the accompanying solution document before making any changes.

1.3.5.1 Mitigation Recommendations¶

Patch Validation and Software Hygiene

Validate all deployed Ivanti Connect Secure appliances against the latest vendor advisories
Ensure software versions meet or exceed the patch levels specified in the mitigation sections of CVE-2025-22457, CVE-2023-46805, and CVE-2024-21887
Monitor for out-of-band firmware updates and emergency hotfixes from Ivanti and CISA

Asset Management and Attack Surface Reduction

Use SentinelOne Ranger or equivalent tools to discover unmanaged or rogue VPN appliances, IoT devices, and remote endpoints
Maintain a centralized asset inventory that includes:
Network infrastructure (firewalls, switches, VPNs)
Server Compute
Medical devices and embedded systems
End-user workstations and mobile devices
Cloud workloads and virtual appliances
Tag critical assets (VPN gateways, EHR systems) for prioritized alerting and patch enforcement

Network Segmentation and Access Control

Isolate Ivanti appliances from direct internet exposure where possible
Enforce strict ACLs and firewall rules to limit access to endpoints
Require MFA for all VPN access

1.3.5.2 Detection Enhancements¶

Sigma Rule Deployment

Deployment of Sigma rules related to the CVEs. Sigma rules enhance log-based detection across multiple platforms. Recommended log sources include:

Windows Sysmon / Event Logs: Detect shell execution, credential access, and process injection (e.g., TRAILBLAZE behavior)
Suricata IPS: Match exploit signatures for login.cgi and welcome.cgi injection attempts. Use Sid 22457 for CVE-2025-22457
Firewall Logs: Adapt Sigma rules to detect anomalous outbound traffic, reverse shells, and passive beaconing
Azure Security Center / Defender XDR: Translate Sigma logic into KQL queries to detect command injection, webshell activity, and lateral movement
Ivanti Connect Secure Logs: Monitor HTTP access logs for exploit chains involving login.cgi, welcome.cgi, and suspicious POST bodies
Splunk SIEM / SOAR: Use Sigma2Splunk converters to build correlation searches, risk-based alerts, and automated playbooks
SentinelOne Singularity Endpoint: While Sigma is not natively supported, logic can be translated into Storyline Active Response (STAR) rules or hunting queries
CrowdSec: Convert Sigma rules into YAML-based scenarios. CrowdSec supports behavioral detection and can trigger bouncer actions (e.g., IP blocking, Discord alerts)

YARA Rule Deployment

YARA rules support malware identification, endpoint detection, and forensic triage. Recommended integrations:

SentinelOne Deep Visibility: Scan memory and file artifacts for BRUSHFIRE, TRAILBLAZE, and SPAWN variants. Supports custom indicators
Ivanti Connect Secure Appliance: Use YARA to scan /home/bin/web and other implant paths if file access is available via SSH or forensic imaging
Splunk: Integrate YARA via scripted inputs or sandbox connectors (e.g., Cuckoo, VMRay) for malware analysis
Microsoft Defender for Office 365: Apply YARA in sandboxed email attachment analysis and phishing lure detection
Azure Security Center / Defender for Endpoint: Use YARA for file scanning and memory inspection across cloud workloads and hybrid endpoints
DLP Solutions: Apply YARA to scan outbound files for sensitive content (e.g., PHI, PII, credentials) before transmission

1.3.5.3 Additional Recommendations¶

File Integrity Monitoring (FIM)
SentinelOne enhancements
Ranger
STAR
Passive DNS and Proxy Analysis
Threat Intelligence enhancements, integration of existing tools and CrowdSec into current workflows
Deployment of Splunk SOAR as an enhancement to the existing toolset
Automate response actions such as:
- Endpoint isolation
- Ticket creation
- Threat enrichment
- SOC notification
Deployment of a Data Loss Prevention (DLP) solution to add additional internal controls geared towards protecting sensitive data (HIPAA/PHI/PII)

2. Security Operations Center - Detection Strategy and Rule Deployment¶

2.1 Purpose¶

This section outlines the detection logic, rule formats, and platform-specific integrations designed to identify exploitation attempts and post-compromise activity related to CVE-2025-22457, CVE-2023-46805, and CVE-2024-21887. The rules can be deployed across a multi-platform SOC environment, including SentinelOne, Splunk, CrowdSec, Suricata, and DLP solutions. Each rule is mapped to MITRE ATT&CK techniques and aligned with the threat intelligence findings in Section 1. The goal is to provide reproducible detection logic that supports both automated response and forensic triage.

2.2 Critical Log Sources and Telemetry¶

2.2.1 Critical Log Sources¶

Category	Source	Why It's Critical
VPN Gateway Logs	Ivanti Connect Secure HTTP access logs (welcome.cgi, login.cgi, DSID cookies)	Detects initial access, exploit attempts, and webshell injection (T1190, T1059.004)
Web Server Logs	Webserver(s) logs on Ivanti appliance or reverse proxy	Captures command injection, unusual POSTs, and shell payloads
Process Creation	Sysmon (Windows), auditd (Linux), SentinelOne Deep Visibility	Detects TRAILBLAZE execution, shell spawns, and BRUSHFIRE injection (T1059.004, T1057)
File Integrity Monitoring	SentinelOne	Flags changes to /home/bin/web, dropped implants, or tampered ICT binaries (T1505.003, T1222)
Network Traffic	Suricata/Snort, firewall logs, CrowdSec decisions	Identifies passive beaconing, reverse shells, and lateral movement (T1071.001, T1021.002)
Authentication Logs	VPN login events, AD/LDAP logs, MFA failures	Detects credential harvesting, session hijacking, and brute force attempts (T1003, T1033)
Endpoint Telemetry	SentinelOne, Defender for Endpoint, CrowdSec agent	Tracks shell execution, memory-only payloads, and suspicious child processes
DNS & Proxy Logs	Internal DNS, web proxy, Secure Web Gateway	Reveals C2 domains, encoded payloads, and exfiltration attempts (T1041)
Email Security Logs	Defender for O365	Detects phishing lures targeting VPN credentials or fake Ivanti updates
Asset Inventory & Vulnerability Scans	Qualys, SentinelOne Ranger	Identifies vulnerable Ivanti appliances and unmanaged VPN endpoints
Cloud App Logs	Azure App Service, Defender for Cloud	Detects command injection patterns (cmd=, ;, &) in cloud-exposed Ivanti services

2.2.2 MITRE Technique Telemetry Coverage¶

MITRE Technique	Required Telemetry
T1190 – Exploit Public-Facing App	VPN logs, web server logs
T1059.004 – Unix Shell	Process creation, shell history
T1505.003 – Webshell	File integrity, process injection
T1562.001 – Disable Security Tools	ICT tampering, log suppression
T1071.001 – Web C2	Firewall / IPS (Suricata) logs
T1003 – Credential Dumping	EDR/Auth logs, memory inspection
T1041 – Exfiltration	DNS, firewall logs
T1021.004 – SSH	Network traffic, process logs
T1033 – User Discovery	Endpoint telemetry, shell history
T1222 – File Permissions	FIM, auditd, SentinelOne
T1518.001 – Security Software Discovery	Process logs, endpoint scans
T1027 – Obfuscated Files or Information	File content inspection, script decoding, memory analysis
T1036 – Masquerading	Process lineage, binary metadata, DLL loading anomalies
T1016 – System Network Configuration Discovery	Network interface logs, shell commands (ip, ifconfig)
T1057 – Process Discovery	Process listings, auditd
T1082 – System Information Discovery	OS fingerprinting, hostname queries, system metadata
T1083 – File and Directory Discovery	File access logs, shell history, auditd

2.3 Detection Rule Suggestions¶

2.3.1 YARA Rules for Detection¶

This section outlines YARA-based detection logic for identifying memory-resident implants and file-based indicators. These rules can be applied across the security stack, SentinelOne, Microsoft Defender, DLP solutions and forensic platforms.

BRUSHFIRE Backdoor

rule BRUSHFIRE_Backdoor
{
    meta:
        description = "Detects BRUSHFIRE passive backdoor"
        author = "Paul Leone"
        cve = "CVE-2025-22457"

    strings:
        $s1 = "BRUSHFIRE::init"
        $s2 = "/home/bin/web"
        $s3 = "passive_beacon_mode"

    condition:
        all of them
}

SPAWN Toolset Detection Rules

rule M_APT_Installer_SPAWNANT_1
{
    meta:
        author = "Mandiant"
        description = "Detects SPAWNANT. SPAWNANT is an Installer targeting Ivanti devices. Its purpose is to persistently install other malware from the SPAWN family (SPAWNSNAIL, SPAWNMOLE) as well as drop additional webshells on the box."

    strings:
        $s1 = "dspkginstall" ascii fullword
        $s2 = "vsnprintf" ascii fullword
        $s3 = "bom_files" ascii fullword
        $s4 = "do-install" ascii
        $s5 = "ld.so.preload" ascii
        $s6 = "LD_PRELOAD" ascii
        $s7 = "scanner.py" ascii

    condition:
        uint32(0) == 0x464c457f and 5 of ($s*)
}

rule M_Utility_SPAWNSNARE_1
{
    meta:
        author = "Mandiant"
        description = "SPAWNSNARE is a utility written in C that targets Linux systems by extracting the uncompressed Linux kernel image into a file and encrypting it with AES."

    strings:
        $s1 = "\x00extract_vmlinux\x00"
        $s2 = "\x00encrypt_file\x00"
        $s3 = "\x00decrypt_file\x00"
        $s4 = "\x00lbb_main\x00"
        $s5 = "\x00busybox\x00"
        $s6 = "\x00/etc/busybox.conf\x00"

    condition:
        uint32(0) == 0x464c457f and all of them
}

rule M_APT_Utility_SPAWNSLOTH_2
{
    meta:
        author = "Mandiant"
        description = "Hunting rule to identify strings found in SPAWNSLOTH"

    strings:
        $dslog = "dslogserver" ascii fullword
        $hook1 = "g_do_syslog_servers_exist" ascii fullword
        $hook2 = "ZN5DSLog4File3addEPKci" ascii fullword
        $hook3 = "funchook" ascii fullword

    condition:
        uint32(0) == 0x464c457f and all of them
}

2.3.2 Suricata Intrusion Prevention System Detection Rules¶

Exploit Attempt Detection

alert http $EXTERNAL_NET any -> $HOME_NET any (msg:"Ivanti CVE-2025-22457 Exploit Attempt"; flow:to_server,established; content:"/dana-na/auth/url_default/welcome.cgi"; http_uri; content:"TRAILBLAZE"; http_client_body; classtype:attempted-admin; sid:22457; rev:1;)

Shell Dropper Detection

alert tcp $EXTERNAL_NET any -> $HOME_NET 443 (msg:"Ivanti CVE-2025-22457 Shell Dropper"; flow:to_server,established; content:"#!/bin/sh"; content:"TRAILBLAZE"; content:"BRUSHFIRE"; sid:224572025; rev:1;)

2.3.3 SentinelOne¶

Recommended enhancements to SentinelOne Singularity Endpoint that strengthen detection and response for Ivanti-related threats:

Deep Visibility

Enables granular telemetry across endpoints, capturing process execution, memory artifacts, and file operations — essential for detecting in-memory payloads like TRAILBLAZE and stealthy implants like BRUSHFIRE.

2.3.4 CrowdSec Detection Scenarios¶

CrowdSec scenarios use YAML rules to analyze logs and trigger actions. They work with web, VPN, and optionally Suricata logs to spot brute force and exploit attempts. You can also set up remediation nodes for automatic rule updates with known C2 IPs.

Scenario: Ivanti Auth Bypass via DSID Cookie

name: crowdsecurity/ivanti-auth-bypass
description: Detects suspicious DSID cookie usage targeting Ivanti welcome.cgi
filter: |
  evt.Meta.log_type == 'http_access-log' &&
  Lower(evt.Meta.http_path) contains "/dana-na/auth/url_default/welcome.cgi" &&
  Lower(evt.Meta.http_cookie) contains "dsid="
groupby: evt.Meta.source_ip
distinct: evt.Meta.http_cookie
capacity: 5
leakspeed: 10m
labels:
  type: exploit
  remediation: true
  classification:
    - attack.initial_access
    - cve.CVE-2023-46805

Scenario: Ivanti Command Injection via login.cgi

name: crowdsecurity/ivanti-command-injection
description: Detects suspicious cmd= injection attempts in Ivanti login.cgi
filter: |
  evt.Meta.log_type == 'http_access-log' &&
  Lower(evt.Meta.http_path) contains "/dana-na/auth/url_default/login.cgi" &&
  Lower(evt.Meta.http_body) contains "cmd=" &&
  (
    Lower(evt.Meta.http_body) contains "%3b" or
    Lower(evt.Meta.http_body) contains "%26" or
    Lower(evt.Meta.http_body) contains "%2f"
  )
groupby: evt.Meta.source_ip
distinct: evt.Meta.http_body
capacity: 3
leakspeed: 5m
labels:
  type: exploit
  remediation: true
  classification:
    - attack.execution
    - cve.CVE-2024-21887

Scenario: Ivanti Custom Detection for CVE-2025-22457 / TRAILBLAZE

name: crowdsec/ivanti_cve_2025_22457
description: Detects exploitation attempts of CVE-2025-22457
filter: |
  evt.Meta.service == "http" &&
  evt.Meta.http_path contains "/dana-na/auth/url_default/welcome.cgi" &&
  evt.Meta.http_body contains "TRAILBLAZE"
groupby: evt.Meta.source_ip
blackhole: 5m
labels:
  type: exploit
  remediation: true
  classification: CVE-2025-22457

2.3.5 Firewall Filter Rules¶

CrowdSec remediation service deployed on the NG Firewall can ingest firewall rules via packages or block lists.

CrowdSec Deployed Scenarios

Example of deployed Scenarios:

CrowdSec Deployed Scenarios

2.3.6 File Integrity Monitoring (FIM)¶

Monitor critical paths such as /home/bin/web, /tmp/, and /var/log/ for unauthorized changes, implant drops, and log tampering.

Use cases:

SentinelOne for kernel-level monitoring and behavioral detection of file modifications
CrowdSec to detect suspicious file access patterns and correlate with behavioral scenarios (e.g., unexpected shell activity or log suppression)
Splunk SOAR to ingest FIM alerts and trigger automated playbooks (e.g., isolate asset, enrich with threat intel, notify SOC)

2.3.7 Passive DNS and Proxy Analysis Track outbound connections to known C2 domains used by BRUSHFIRE, ZIPLINE, and other UNC5221 tooling.

Flag:

Encoded payloads (e.g., Base64 in HTTP POST bodies)
Suspicious user agents (e.g., curl, wget, custom implants)

2.3.8 Sigma Rules and Splunk Correlation Logic¶

These queries and rules are designed to detect Ivanti exploitation activity across multiple stages of the kill chain, from initial access to post-exploitation. They correlate logs from:

Ivanti VPN appliances (e.g., login.cgi, welcome.cgi)
Suricata alerts (network-based IDS signatures)
System audit logs (Windows Sysmon, Linux auditd)

Each Search Processing Language (SPL) query or rule targets specific behaviors:

Webshell drop detection (e.g., TRAILBLAZE payloads)
Suricata alert correlation for CVE-specific signatures
Post-exploitation activity like file creation and beaconing

Sigma Rule: Webshell Drop via Ivanti Exploit

title: Ivanti Connect Secure Webshell Drop
id: 9e8b3c3e-4685-4c87-9f3e-ivanti-webshell
status: experimental
description: Detects suspicious file creation in Ivanti Connect Secure directories
logsource:
  product: windows
  category: file_create
detection:
  selection:
    TargetFilename|contains:
      - '\temp\'
      - '\htdocs\'
    Image|contains:
      - 'cmd.exe'
      - 'powershell.exe'
  condition: selection
fields:
  - TargetFilename
  - Image
  - User
  - CommandLine
level: high
tags:
  - attack.initial_access
  - attack.persistence
  - cve.CVE-2023-46805
  - cve.CVE-2024-21887

Splunk Alert and Query Translations

[Ivanti Connect Secure Webshell Drop]
alert.severity = 4
description = Detects suspicious file creation in Ivanti Connect Secure directories (Rule ID: 9e8b3c3e-4685-4c87-9f3e-ivanti-webshell) Reference: https://tdm.socprime.com/tdm/info/
cron_schedule = 0 * * * *
disabled = 1
is_scheduled = 1
is_visible = 1
dispatch.earliest_time = -60m@m
dispatch.latest_time = now
search = index=* source="WinEventLog:*" AND ((TargetFilename="*\\temp\\*" OR TargetFilename="*\\htdocs\\*") AND (NewProcessName="*cmd.exe*" OR NewProcessName="*powershell.exe*")) | table TargetFilename,NewProcessName,User,CommandLine
alert.suppress = 0
alert.track = 1
actions = risk,notable
action.risk = 1
action.risk.param._risk_object_type = user
action.risk.param._risk_score = 75
action.correlationsearch = 0
action.correlationsearch.enabled = 1
action.notable.param.rule_title = Ivanti Connect Secure Webshell Drop
action.notable.param.rule_description = Detects suspicious file creation in Ivanti Connect Secure directories (Rule ID: 9e8b3c3e-4685-4c87-9f3e-ivanti-webshell)

Ivanti Exploit Chain Detection (Webshell Drop)

index=web_logs sourcetype=ivanti_http_logs
| search uri="/dana-na/auth/url_default/welcome.cgi" AND cookie="DSID="
| join source_ip [ search index=web_logs uri="/dana-na/auth/url_default/login.cgi" body="cmd=" OR body="TRAILBLAZE" ]
| stats count by source_ip, uri, user_agent, body
| where count > 2

Suricata Alert Correlation (Sid 468051 + 218871 + 22457)

index=suricata sourcetype=suricata_eve
| search alert.signature IN (
    "EXPLOIT – Ivanti Connect Secure Authentication Bypass",
    "EXPLOIT – Ivanti Connect Secure Command Injection",
    "EXPLOIT – Ivanti Connect Secure Buffer Overflow CVE-2025-22457"
)
| stats count by src_ip, dest_ip, alert.signature, timestamp
| where count > 1

File Creation + Network Beaconing (Post-Exploitation)

index=os_logs sourcetype=linux_audit OR sourcetype=windows_sysmon
| search process_name="cmd.exe" OR process_name="powershell.exe" OR process_name="TRAILBLAZE"
| join host [ search index=network_logs dest_port=443 OR dest_port=8443 ]
| stats count by host, process_name, dest_ip, uri
| where count > 3

2.4 Workflow and Feature Enhancements to Existing Solutions¶

2.4.1 SentinelOne Singularity Endpoint¶

Recommended enhancements to SentinelOne that provide increased asset visibility and streamline workflows for Ivanti-related threats:

Device Inventory

Automatically discovers and tracks all endpoints, including Windows, Linux, macOS and cloud workloads. Displays hostname, OS, IP, MAC address, agent status and more. Tag assets by site, group, policy, and criticality level for triage and prioritization.

Ranger

Performs passive network discovery to identify unmanaged or rogue devices, including vulnerable Ivanti VPN appliances. Helps map the full attack surface and flag assets missing endpoint protection. Supports agentless visibility using passive network scanning.

STAR (Storyline Active Response)

SentinelOne's custom detection engine that correlates process chains, flags suspicious behavior (shell spawn from web process), and automates response actions like isolation, alerting, and enrichment.

Create custom STAR detection rules for suspicious behaviors linked to these CVEs
Storyline Correlation Logic:
Web process spawning shell interpreters
Encoded payloads (e.g., base64, PowerShell) from web-facing services
Outbound HTTPS connections from non-browser processes

Example Detection Rules:

Rule: Suspicious Webshell Drop
ProcessName: powershell.exe OR cmd.exe
CommandLine: contains "echo" AND contains ".aspx" OR ".jsp"
ParentProcess: httpd.exe OR nginx.exe OR unknown
Tags: ["ivanti", "webshell", "CVE-2023-46805"]

Rule: Command Injection via login.cgi
ProcessName: bash OR sh OR python
CommandLine: contains "cmd=" AND contains ";"
ParentProcess: httpd OR nginx OR unknown
Tags: ["ivanti", "command-injection", "CVE-2024-21887"]

Rule: Buffer Overflow Dropper
ProcessName: cmd.exe OR powershell.exe OR TRAILBLAZE
CommandLine: contains "BRUSHFIRE" OR "/home/bin/web"
ParentProcess: httpd OR nginx OR unknown
Tags: ["ivanti", "dropper", "CVE-2025-22457"]

Storyline Correlation Examples:

httpd.exe → powershell.exe → curl.exe → remote IP
Flag this as suspicious lateral movement or C2 beaconing
httpd.exe → TRAILBLAZE → BRUSHFIRE → outbound HTTPS
Memory-only execution with no file artifacts
Reverse shell or passive beaconing from /home/bin/web

2.4.2 SOAR Playbooks¶

Integrating a SOAR platform into the current SOC toolset will facilitate the automation of response actions across multiple platforms.

Endpoint Isolation

Trigger via SentinelOne or Defender for Endpoint
Use Splunk SOAR to orchestrate across hybrid environments

Ticket Creation

Auto-generate tickets in ITSM platforms (ServiceNow, Jira) with full context from CrowdSec, SentinelOne, and Splunk

Threat Enrichment

Pull CVE metadata, MITRE mappings, and malware family details into alert context
Use Splunk SOAR to enrich alerts with Sigma/YARA matches and IOC overlays

SOC Notification

Send real-time alerts to Slack, Teams, or email with full triage context
Include asset tags, exploit chain stage, and recommended response actions

Ivanti-Specific Logic

Detect access to /dana-na/auth/url_default/login.cgi with cmd= or TRAILBLAZE payloads
Flag modifications to /home/bin/web and disablement of dslogserver
Correlate with Suricata Sid 22457 and CrowdSec exploit scenarios

2.4.3 Threat Intelligence Integration¶

Enrich detections with IOCs from:

CISA AA25-22457
Health-ISAC
Commercial feeds (Recorded Future, Proofpoint, SentinelOne Threat Intel)

Use cases:

Splunk SOAR to ingest threat intel feeds and correlate with asset criticality, MITRE techniques, and recent alerts
SentinelOne STAR to tag assets and apply custom detection logic based on threat indicators
CrowdSec to ingest IOCs into its decision engine and trigger bouncer actions (e.g., IP block, Discord alert)
DLP solution to apply threat intel to outbound file scanning and block transmission of known malware or sensitive content

2.4.4 Passive DNS and Proxy Analysis¶

Workflow use cases:

CrowdSec to detect repeated outbound attempts, DNS tunneling, or proxy evasion. CrowdSec scenarios can block IPs and log decisions for SOC review
Splunk SOAR to correlate proxy anomalies with endpoint behavior (e.g., shell spawn → outbound HTTPS → C2 domain)
DLP solution to inspect outbound traffic for sensitive data exfiltration (e.g., PHI, credentials) and enforce transmission policies

2.4.5 Integration Notes¶

Splunk SOAR can ingest alerts from Sigma, Suricata, CrowdSec, and YARA-based sandboxing tools to automate triage, ticketing, and endpoint isolation. SOAR playbooks can trigger based on Sigma-matched alerts
SentinelOne STAR can be enriched with YARA hits and CrowdSec decisions to trigger behavioral response actions
CrowdSec scenarios can be mapped to MITRE techniques and used to block IPs, trigger alerts, or forward decisions to SIEM/SOAR platforms
DLP solutions (Microsoft Purview, CoSoSys, Forcepoint) can apply YARA rules to scan outbound files for implants or sensitive content

2.5 New Platform and Technology Acquisitions¶

2.5.1 CrowdSec Threat Intelligence¶

Deploying CrowdSec introduces a collaborative, behavior-based defense layer that strengthens detection and response across network and system activity. It's especially valuable for small healthcare organizations seeking lightweight, scalable protection against exploitation attempts, credential abuse, and lateral movement, including those tied to CVE-2025-22457, CVE-2023-46805, and CVE-2024-21887.

Options include: CrowdSec Community Edition (free), CrowdSec Premium (with extended telemetry and support)

Key Capabilities to Prioritize:

Behavioral Detection

Detect brute force, command injection, and suspicious shell activity using YAML-based scenarios mapped to MITRE techniques.

Log Source Integration

Ingest logs from firewalls, VPNs, Suricata, SSH, and systemd to monitor for Ivanti-specific exploit chains and post-exploitation behavior.

Bouncer Actions

Automatically block malicious IPs, disable user accounts, or trigger alerts based on real-time decisions.

Community Threat Intelligence

Leverage global signals from other CrowdSec users to enrich local detections and prioritize emerging threats.

Sigma Rule Conversion

Translate Sigma rules into CrowdSec scenarios to detect known attack patterns and anomalies.

SOAR Integration

Forward CrowdSec decisions to Splunk SOAR for automated triage, ticketing, and enrichment alongside SentinelOne and DLP alerts.

Strategic Benefits:

Adds real-time behavioral detection to VPN and endpoint telemetry
Enables automated blocking of known malicious IPs and exploit attempts
Provides community-driven threat intelligence without heavy infrastructure
Enhances visibility into Ivanti-related attack flows with minimal overhead

2.5.2 Splunk SOAR¶

Deploying Splunk SOAR enables automated, scalable incident response tailored to healthcare environments. It's especially critical when facing multi-stage attacks like those exploiting Ivanti VPN infrastructure, where rapid triage and coordinated response are essential.

Options include: Splunk SOAR Cloud, Splunk SOAR On-Prem, or Splunk SOAR Lite for smaller teams

Key Capabilities to Prioritize:

Playbook Automation

Build workflows to isolate endpoints, enrich alerts, notify SOC teams, and escalate incidents based on severity and asset criticality.

Threat Intelligence Correlation

Integrate feeds from CISA, Health-ISAC, SentinelOne, CrowdSec, and DLP tools to enrich alerts with CVE, malware, and MITRE context.

Asset-Aware Response

Tag critical assets (VPN gateways, EHR systems) and prioritize response actions accordingly.

IOC Matching and Enrichment

Automatically match incoming alerts against known indicators (BRUSHFIRE domains, ZIPLINE hashes) and enrich with MITRE technique mappings.

Cross-Platform Integration

Connect with SentinelOne, Microsoft Defender, CrowdSec, Qualys, and DLP tools to orchestrate unified response.

Case Management and Reporting

Track incident lifecycle, generate audit-ready reports, and support HIPAA compliance documentation.

Strategic Benefits:

Enables rapid containment of Ivanti-related threats across endpoints, networks, and cloud
Reduces SOC fatigue through automated triage and enrichment
Ensures consistent, policy-driven response across all security tools
Supports forensic investigation and compliance reporting for PHI/PII incidents

2.5.3 DLP Solution¶

Implementing a DLP solution introduces critical internal controls designed to protect sensitive healthcare data, including HIPAA-regulated PHI, PII, and financial records. This is especially vital in the context of Ivanti exploitation, where attackers may gain access to VPN-connected endpoints and attempt data exfiltration.

Options include: Microsoft Purview, CoSoSys and Forcepoint DLP for small organizations

Key Capabilities to Prioritize:

Content Inspection

Deep scanning of files, emails, and web uploads for sensitive data.

Policy Enforcement

Block or quarantine outbound transmissions that violate data handling policies, especially from compromised endpoints or VPN sessions.

Endpoint Integration

Monitor clipboard activity, USB transfers, and file access on workstations and mobile devices. Detect attempts to move PHI outside approved channels.

Network DLP

Inspect outbound traffic for encrypted payloads, ZIPLINE-style reverse shells, or BRUSHFIRE beaconing that may contain exfiltrated data.

YARA Rule Support

Apply custom YARA rules to scan for malware-laced documents or implants attempting to masquerade as legitimate healthcare files.

SOAR Integration

Forward DLP alerts to Splunk SOAR for automated triage, ticketing, and endpoint isolation. Include context from CrowdSec decisions and SentinelOne Deep Visibility.

Strategic Benefits:

Prevents unauthorized transmission of PHI/PII during or after exploitation of VPN infrastructure
Adds a compensating control for organizations with limited segmentation or endpoint hardening
Enables forensic triage of suspected data theft attempts tied to CVE-2025-22457, CVE-2023-46805, and CVE-2024-21887

2.6 Detection Rule Summary Table¶

Rule Type	Target Platform(s)	CVE Coverage	MITRE Technique(s)	Detection Purpose
YARA	SentinelOne, Defender, DLP	CVE-2025-22457	T1059.004, T1505.003	Detect BRUSHFIRE and SPAWN implants
Sigma	Splunk, CrowdSec	CVE-2023-46805, 2024-21887	T1190, T1071.001	Detect Ivanti exploit chains and webshells
Suricata	Suricata, CrowdSec	CVE-2025-22457	T1190, T1059.004	Detect buffer overflow and shell dropper
CrowdSec	CrowdSec, Splunk SOAR	All three CVEs	T1190, T1059.004	Detect command injection and auth bypass

This table supports SOC onboarding, dashboard filtering, and cross-platform rule deployment.

Conclusion¶

This comprehensive threat intelligence brief and SOC enhancement plan provides Piedmont Medical Group with actionable strategies to defend against UNC5221 exploitation of Ivanti Connect Secure infrastructure. The detection rules, workflow enhancements, and platform recommendations are designed to integrate seamlessly with existing security tools while providing layered defense against sophisticated threat actors targeting the healthcare sector.

Key Takeaways:

Immediate patching of CVE-2025-22457, CVE-2023-46805, and CVE-2024-21887 is critical
Multi-layer detection through YARA, Sigma, Suricata, and CrowdSec rules provides comprehensive coverage
SOAR automation reduces response times and analyst fatigue
DLP controls protect PHI/PII from exfiltration during or after compromise
Threat intelligence integration enriches detection fidelity and contextual awareness

Next Steps:

Review and validate current Ivanti patch levels
Deploy detection rules to appropriate platforms (Splunk, SentinelOne, Suricata, CrowdSec)
Configure SOAR playbooks for automated response
Enable SentinelOne Ranger for asset discovery
Implement FIM monitoring on critical paths
Integrate threat intelligence feeds
Conduct tabletop exercises to validate detection and response workflows

Document Version: 1.0
Last Updated: October 6, 2025
Classification: Internal Use Only
Distribution: PMG IT Security Team, SOC Analysts, Incident Response Team

For questions or clarifications regarding this document, contact Paul Leone at pnleone@outlook.com

Threat Intelligence Brief and SOC Enhancement Plan¶

1. Threat Intelligence Brief¶

1.1 Purpose¶

1.2 Overview of UNC5221 Threat Landscape¶

1.2.1 Background¶

1.2.2 Related Campaigns¶

1.3 Threat Analysis – Ivanti Connect Secure¶

1.3.1 Vulnerabilities Overview¶

CVE-2023-46805 – Ivanti Connect Secure / Policy Secure Authentication Bypass¶

CVE-2024-21887 – Ivanti Command Injection¶

CVE-2025-22457 - Ivanti Stack-Based Buffer Overflow¶

1.3.2 Related Toolset¶

Summary¶

TRAILBLAZE¶

BRUSHFIRE¶

SPAWNSLOTH¶

SPAWNWAVE¶

ZIPLINE¶

BRICKSTORM¶

EARTHWORM¶

LIGHTWIRE¶

NEO-reGEORG¶

1.3.3 MITRE ATT&CK Mapping for Ivanti CVEs¶

1.3.4 Risk Assessment¶

1.3.5 Recommendations for Mitigation and Detection¶

1.3.5.1 Mitigation Recommendations¶

1.3.5.2 Detection Enhancements¶

1.3.5.3 Additional Recommendations¶

2. Security Operations Center - Detection Strategy and Rule Deployment¶

2.1 Purpose¶

2.2 Critical Log Sources and Telemetry¶

2.2.1 Critical Log Sources¶

2.2.2 MITRE Technique Telemetry Coverage¶

2.3 Detection Rule Suggestions¶

2.3.1 YARA Rules for Detection¶

2.3.2 Suricata Intrusion Prevention System Detection Rules¶

2.3.3 SentinelOne¶

2.3.4 CrowdSec Detection Scenarios¶

2.3.5 Firewall Filter Rules¶

2.3.6 File Integrity Monitoring (FIM)¶

2.3.8 Sigma Rules and Splunk Correlation Logic¶

2.4 Workflow and Feature Enhancements to Existing Solutions¶

2.4.1 SentinelOne Singularity Endpoint¶

2.4.2 SOAR Playbooks¶

2.4.3 Threat Intelligence Integration¶

2.4.4 Passive DNS and Proxy Analysis¶

2.4.5 Integration Notes¶

2.5 New Platform and Technology Acquisitions¶

2.5.1 CrowdSec Threat Intelligence¶

2.5.2 Splunk SOAR¶

2.5.3 DLP Solution¶

2.6 Detection Rule Summary Table¶

Conclusion¶
